- Ultra-fast PCIe Gen4 x4 interface Capacity
- Compliant with NVMe 1.4
- R/W speed up to 5,000/2,700MB/s
- Work with PS5
- Read speed up to 4,000MB/s for PS5
- Advanced hardware LDPC ECC Technology
- Supports Host Memory Buffer (HMB)
- AES 256-bit encryption support
- Great upgrade option for creators
- Compact M.2 2280 form factor – Designed for professional-level tasks such as 3D graphics, film production, computer-aided engineering, etc.
- Free software: SSD ToolBox
Specification | |
Capacity | 512 GB |
Controller | SMI SM2269XT |
NAND Flash | 3D NAND |
Interface | PCIe Gen4 x4 |
Form factor | M.2 2280 |
MTBF | 2,000,000 hours |
TBW | 500TB |
Dimensions (L x W x H) | 80 x 22 x 3.13mm (with heat sink)
80 x 22 x 2.15mm (without heat sink) |
Weight | 5g / 0.17oz (with heat sink)
4g / 0.14oz (without heat sink) |
Sequential Performance | Read Up to 5000MB/s, Write Up to 2700MB/s
PS5 Seq. Read: Up to 4000MB/s |
4K Random | Read (IOPS) 380K, Write (IOPS) 530K |
Operating temperature | 0°C-70°C |
Storage temperature | -40°C-85°C |
Shock resistance | 1500G/0.5ms |
Certifications | CE, FCC, BSMI, KC, EAC, RCM, morocco, UKCA, RoHS |
Warranty | 5 years limited |
Note* | Price, feature and specifications are subject to change without notice. |
